The expansion tank needs to be installed on the suction side of the hot-water circulator, on the bottom of the supply line. The boiler system is then re-pressurized and should be checked for any leaks. If leaks are found in the system, they need to be repaired to prevent any pressure drops.

Where should expansion tanks be installed?

An expansion tank is generally installed directly above the water heater by means of a tee-fitting installed in the cold water delivery pipe. The expansion tank is usually installed vertically, though it is acceptable to install it horizontally if it is necessary because of space limitations.

Can you install expansion tank anywhere?

An expansion tank, such as the one shown above, helps to absorb water pressure that results from thermal expansion. The tank can be installed anywhere in the cold-water line between the house’s main valve and water heater, or on the hot-water line within 3 ft. to 5 ft. of the water heater.

Why must the expansion tank always be located higher than the boiler?

protect the boiler from excessive water temperatures. … Why must the expansion tank always be located higher than the boiler? To allow air to be pushed up into the expansion tank when adding water into the boiler. The pressure relief valve _____.

Does expansion tank go on hot or cold line?

Expansion tanks are normally installed above the water heater on the cold water line before it enters the water heater; however, they can really be installed anywhere on the cold water line prior to entry into the water heater.

What pressure should my expansion tank be set at?

The recommended water pressure is between 50 and 60 PSI. Thermal Expansion Tanks contain an air bladder which is pressurized with air, and expands and contracts to absorb the expanded water from the water heater. needed. Check the air pressure in the Expansion Tank using a tire gauge.

How close should an expansion tank be to a water heater?

The items which should be installed in sequence in the cold water line are (1) the EXPANSION TANK must be installed at least 18 inches away from the cold water inlet fitting on the water heater, (2) the PRESSURE GAUGE, and (3) the PRESSURE REDUCING VALVE, if required, see Figure 1. 3.

How do I know if my expansion tank is working?

The tank should be full of air and therefore sound hollow. If it makes a dull thud rather than a hollow sound, your tank is full of water and needs repair or replacement. You can also gauge this by feeling the tank, which will be cool where it’s holding air and warm where it’s holding water.

Does the expansion tank have to be above the boiler?

That is the main function of an expansion tank. There are two main types of expansion tanks: Compression and Bladder/Diaphragm. A compression tank (also called a plain steel tank) is always mounted horizontally somewhere above the boiler – the higher the location, the smaller the tank.

How should an expansion tank be mounted?

Expansion tanks can be installed in any direction. Whether oriented uprightly, horizontally, or even upside down, the expansion tank will function properly without any adverse effects. When putting an expansion in an abnormal position (specifically sideways or horizontally), make sure to support the tank.

Article first time published on

Can an expansion tank be installed sideways?

Can a water heater thermal expansion tank be installed sideways/horizontally? Most expansion tanks are designed to be installed vertically (stem up or stem down). You can install one sideways, but it will shorten the lifespan unless it is designed and specified by the manufacturer for horizontal installation.

What size expansion tank do I need for a 40 gallon water heater?

Water Heater CapacitySupply Pressure (psi)Expansion Tank Size40 to 60-gallon40-50 psi2-gallon40 to 60-gallon60-80 psi3.2-gallon80-gallon40 psi2-gallon80-gallon50-60 psi3.2-gallon

Why do expansion tanks go on the cold side?

One expansion tank manufacturer states: “We recommend the cold water side installation because the tank is not insulated. When the expanded volume enters the tank, it will cool down. With the tank on the cold water side, this expanded volume will pass through the water heater before going out to the faucets.”

What does the expansion tank on a boiler do?

The expansion tank is designed to handle the thermal expansion of water as it heats up in the water heater, preventing excessive water pressure. If water pressure gets to high it can damage valves in plumbing fixtures, joints in supply pipes and the water heater itself.

Does an expansion tank need to be supported?

All expansion tanks (even the small 2-gallon tanks) should be supported in some way. … You want to match the pressure in the expansion tank as close as possible to the water pressure of the house.

How do you check expansion tank pressure?

Once you completely open the valve, you can measure and note the pressure. You can also check your expansion tank’s pre-charge pressure by knocking on the side of the tank with your knuckles to determine if it’s full of air or water. Pre-charge pressure that’s too low may be indicated when the tank is full of water.

Can expansion tank cause low water pressure?

Before installing an expansion tank, measure the tank’s air pressure charge. When taken from the box, the air pressure in the expansion tanks will likely be lower than your home’s water pressure.

Is a expansion tank required by code?

The California Plumbing Code (Section 608.3) and the California Mechanical Code (Section 1005.0) requires a thermal expansion tank, or listed equivalent, to be installed to water heating systems to relieve excessive building pressure during the heating process.

Can an expansion tank explode?

As water heats up, it can expand dramatically, and if it’s hot enough to turn into steam, this can add even more pressure to the water heater. If the relief valve is malfunctioning, this can lead to an explosion.

What happens when expansion tank fails?

Oftenthe diaphragm dividing the two systems will fail, causing the two systems to become one. When this happens, the expansion tank turns into a “dead leg” that will eventually cause damage and premature failure to your water heater.

What side does a expansion tank go on?

Although expansion tanks can be installed on the hot side, we strongly recommend they be installed on the cold line, downstream of the shutoff valve.

Can a hot water tank be installed horizontally?

Now you know that you can put your water heater on its side and how you can put it. … By putting your hot water heater horizontally, you can avoid damages like metal casing and glass cracking.

Why does my expansion tank keep filling up?

Not Enough Air in Diaphragm Tank The most common expansion tank problem in a diaphragm tank is losing small amounts of air through the valve. … If the tank does not hold its air pressure after you complete this fix or it fills with excess water, you may need to replace the diaphragm.

What is the red tank next to my boiler?

Expansion vessel: This is a small metal tank, usually red in colour, often located either in or near the boiler or near the hot water cylinder, in which a rubber sheet, or diaphragm, separates central heating water from pressurised air and this can leak allowing water to escape into the ‘air only’ part.
