Many automotive relays are similar in appearance and pin configuration and will plug into the same relay socket, but are completely different in the switching duties they perform. The most common type of relay used in automotive applications is the single pole/double throw (SPDT).

What does a relay plug into?

Many automotive relays are similar in appearance and pin configuration and will plug into the same relay socket, but are completely different in the switching duties they perform. The most common type of relay used in automotive applications is the single pole/double throw (SPDT).

How does a 4 pin relay work?

4 Pin Relay 4 pin relays use 2 pins (85 & 86) to control the coil and 2 pins (30 & 87) which switch power on a single circuit. There are 2 types of 4 pin relay available; normally open or normally closed. A normally open relay will switch power ON for a circuit when the coil is activated.

Where are relays connected?

The COM (Common) connection of a relay is the part of the relay that moves. When a relay is off, the COMMON is connected to the NC (Normally Closed). The NO (Normally Open) connection of the relay is not connected until the relay turns on.

How a relay works 12v?

Relays install between the power source and the electrical accessory requiring on/off power. When the relay is energized, the high current to operate the accessory flows from the power source, through the relay, and directly to the part.

How many terminals does a relay have?

These have two terminals which can be connected or disconnected. Including two for the coil, such a relay has four terminals in total. SPST-NC (Single-Pole Single-Throw, Normally-Closed) relays have a single Form B or break contact.

How do relays work in a circuit?

Relays are switches that open and close circuits electromechanically or electronically. Relays control one electrical circuit by opening and closing contacts in another circuit. … When a relay contact is Normally Closed (NC), there is a closed contact when the relay is not energized.

What is pin 87a on a relay?

87 and 87a are the two contacts to which 30 will connect. If the coil is not activated, 30 will always be connected to 87a. Think of this as the relay in the Normally Closed (OFF) position. When current is applied to the coil, 30 is then connected to pin 87. … If you want a closed relay, you will want to wire to 87a.

When would you use a relay?

One of the most common situations that require the use of a relay occurs when an application needs to switch from high to low current (or vice versa) within the same circuit. For example, the temperature sensors that power HVAC units require levels of amperage that vastly exceed the capacity of their wiring.

What is 86 on a relay?

Realizing that 85 and 86 are the coil pins, these pins will be transferring the current through the coil. 85 will be used to ground your relay, while 86 will be connected to the switchable power. 87 and 87a will be connected to your controlled accessories that you wish to turn on and off with your relay.

Article first time published on

How do you hook up a 12V DC relay?

  1. Connect wires to the coil of your relay. …
  2. Connect the “common” (C) terminal of the relay to a battery supply. …
  3. Connect the power input lead from the equipment you want to operate with the relay to the “normally open” (NO) terminal of the relay.

When should you use a 12V relay?

Most 12 volt relays operate the accessories in cars and other motor vehicles. When you apply a small amount of current to the relay coil, this closes contacts which in turn feed power to an accessory which would normally require a lot of current to operate.

What is the difference between a contactor and a relay?

A contactor joins 2 poles together, without a common circuit between them, while a relay has a common contact that connects to a neutral position. Additionally, contactors are commonly rated for up to 1000V, while relays are usually rated to only 250V.

Which are the two types of relays?

  • Relays are electrically operated switches. …
  • Electromechanical relays have an electromagnetic coil and a mechanical movable contact. …
  • Solid-state relays are solid-state electronic components that do not have any moving components, which increases their long-term reliability.

Why a relay is always connected to a circuit breaker?

Most standard circuit-breakers can be equipped with trip coils for any of the mentioned voltages. … When the relay operates it opens these contacts, and allows the current from the current transformers to flow through the trip coil and thus operate the breaker.

Do I need to use a relay for LED lights?

A relay is an electrical switch that lets a low current circuit control a high current circuit such as a large LED light bar. … If you are using a light pod that does not have a very large amp draw, you may not need a relay switch, but if you are using a larger LED light bar, they are a must have.

Is a relay the same as a fuse?

Fuses are included on all your car’s various electrical circuits to protect components from surges of electricity. … Relays are remote switches that open or close an electrical circuit. For example, only a little electricity is needed for the headlight switch that turns your headlights on and off.

Why is a relay better than a switch?

While a relay does add an extra step to the switching process, the main advantage is that you can leave the actual switching of high-power circuits for things like off-road lights or air compressors in the engine compartment, and control that switching with a much smaller amperage circuit that energizes the relay’s …

When should you use a relay on a car?

Relays are often used in circuits to reduce the current that flows through the primary control switch. A relatively low amperage switch, timer, or sensor can be used to turn a much higher capacity relay on and off. Another primary use for relays is when upgrading to halogen headlights on an older car.

What does 31 mean on a wiring diagram?

For exam- ple, a terminal 31 designation always refers to a direct connection to vehicle ground and a terminal 30 designation always represents a direct connection to the battery positive terminal.

What is Terminal 30 on a relay?

Terminal 30 supplies power to one of the internal switch contacts. Terminal 87 connects the other internal switch contact to the device controlled by the relay.

What is relay latching?

“Latching relay” is a generic term that is used to describe a relay that maintains its contact position after the control power has been removed. Latching relays allow a customer to control a circuit by simply providing a single pulse to the relay control circuit.

What is a 52 relay?

52 AC circuit breaker A device that is used to close and interrupt an AC power circuit under normal conditions or to interrupt this circuit under fault or emergency conditions.

What is a 59 relay?

#Name50Instantaneous Overcurrent51Inverse-Time Overcurrent52Circuit Breaker59Overvoltage

What is a 50 relay?

On electromechanical relays, the 50 function can be added as an instantaneous attachment to a 51 time-overcurrent relay. If a relay has both 50 and 51 functions present and enabled is referred to as a 50/51 relay. … This relay is referred to as a residual ground overcurrent or 51N (or 50/51N) relay.
